TurboLogix Control & Energy Management System for Centrifugal Compressors
Optimize Compressor Performance, Maximize Energy Efficiency, and Minimize Downtime
TurboLogix is a powerful solution designed specifically for centrifugal compressors. By combining Allen-Bradley PLC hardware with field-tested control and energy management software, TurboLogix offers a flexible, user-friendly system that improves compressor performance, reduces downtime, and helps you save energy. Whether you need real-time monitoring, energy savings, or seamless integration into your existing systems, TurboLogix delivers exceptional results.
What is TurboLogix?
TurboLogix combines advanced control technology and energy management software to offer reliable and efficient solutions for your centrifugal compressors. Key features include:
- Real-time Data Viewing
- Performance Trending
- High-speed Data Acquisition via Ethernet Connectivity
TurboLogix’s open architecture ensures easy integration with your existing systems while providing enhanced performance and energy savings.
Key Features of TurboLogix
TurboLogix is designed to improve energy efficiency, performance monitoring, and system integration. Here’s how it works:
Real-Time Monitoring
Monitor your compressor’s performance in real-time, tracking critical metrics to ensure it’s running optimally.
Energy-Saving
TurboLogix offers energy-saving features that reduce energy consumption, especially during off-peak times.
System Integration
TurboLogix easily integrates with existing Distributed Control Systems (DCS), ensuring minimal disruption during setup.
Open Architecture
TurboLogix can integrate with any existing system and allows for customization and future upgrades.
TurboLogix Basic System Configuration: Simple, Flexible, and Powerful
TurboLogix uses a user-friendly open architecture PLC system to monitor, control, and protect centrifugal compressors. Here’s a look at the key components:
- NEMA 12 enclosure (48” x 30” x 10”) with sub-panel
- Allen-Bradley CompactLogix L23E processor, I/O, and power supply
- 10.5” color touchscreen operator interface
- Ethernet interface for high-speed data acquisition
- 120vac 15-amp circuit breaker
- AC and DC fusing and terminals
- Prelube pump motor starter (IEC Rated)
- Oil heater contactor (IEC rated)
With over 15 years of proven performance, TurboLogix is a trusted solution for enhancing compressor performance. It’s designed to be flexible and easy to integrate with existing systems. Whether you’re upgrading from an older system or setting up a new one, TurboLogix adapts to your needs.
TurboLogix Control System Upgrades: Tailored to Your Needs
TurboLogix offers customizable upgrade options depending on your specific requirements, from basic functionality to fully customized solutions.
- Allen-Bradley CompactLogix hardware
- Open software architecture for flexibility
- Modbus & Allen-Bradley communication
- 7”–15” color touchscreen operator interface
- Data trending, event logs, and backups
- Energy-saving compensated turn-down
- Fully field-configurable
- DCS-friendly integration
- Enhanced reliability
- TurboGuardian Cloud compatible
Includes all features of TurboLogix® BASIC, plus:
- Customized design panel to fit your needs
- Allen-Bradley ControlLogix hardware upgrade
- Seamless integration with current or obsolete systems
Includes features of both TurboLogix® BASIC and ENGINEERED, plus:
- Quick, easy drop-in retrofit upgrades
- Compatible with any OEM compressor system
- In-house manufacturing for fast delivery
- Modbus RTU, TCP/IP, and Allen-Bradley Ethernet IP communication interfaces
TurboLogix’s energy-saving throttle valve alignment and compressor management system optimize savings by utilizing the inlet guide vane effect from all units. This peer-to-peer design requires no external black box or special hardware, and uses an Ethernet-based communication network for automated compressor start/stop and load/unload operations. TurboLogix is compatible with both electric and turbine-driven centrifugal compressors.
- Fastest installation and setup worldwide
- Energy-efficient operation for all compressor types
TurboLogix offers an Enhanced Performance Monitoring Package designed to pinpoint issues that cause frequent downtime. Key features include:
- Electricity usage/cost measurements
- Inlet and bypass valve performance monitoring
- Oil pressure and filter analysis
- Maintenance alerts for dirty filters
This package is ideal for preventative maintenance, enhanced troubleshooting, and cloud-based analytics, helping minimize field service calls and prevent downtime, ultimately saving customers money.
TurboLogix: An Energy Management Solution for Centrifugal Compressors
TurboLogix is the complete control and energy management solution for centrifugal compressors. By integrating real-time monitoring with advanced analytics, TurboLogix helps you achieve optimal performance and energy efficiency, all while reducing downtime and operational costs. Whether you’re upgrading your existing system or looking for a comprehensive solution, TurboLogix is designed to meet your needs.
Contact Us to Learn More About How to Optimize Your Centrifugal Air Compressor
Ready to integrate TurboLogix into your compressor system? Contact Air Relief today to learn more about how our TurboLogix control systems can enhance your centrifugal compressor’s performance and energy efficiency.
